Pro XS 175-300hp
Mercury Pro XS® outboards are engineered for those boaters who demand ultimate performance – anglers competing on the highly competitive tournament trails and powerboaters who simply crave speed and acceleration. Exclusive components and tuning extract every ounce of performance from each Pro XS model so you can take it to the limit.
TorqueMaster Gearcase
The lightweight TorqueMaster gearcase (featured on select V8 models) has a 1.75:1 gear ratio and a robust 1.25-inch-diameter prop shaft designed for semi-surfacing, high-speed applications.
Transient Spark Technology
Transient Spark Technology electronically adjusts the ignition timing of the engine as needed. This subtle, automatic change produces additional torque for faster hole shot and acceleration.
Adaptive Speed Control
Adaptive Speed Control maintains a desired rpm regardless of changes in load or conditions without adjustments to the throttle lever position – a first for the outboard industry.
Extra Charging Power
A powerful alternator provides net charging output of 20 amps at idle and 85 amps at wide open throttle. Idle Charge battery-management technology automatically increases idle rpm to boost alternator output and recharge low batteries.
Performance-Tuned Exhaust
Exhaust tone has been fine-tuned to provide a brawny performance-inspired sound quality that’s unmistakable on the water yet quieter than competing high-output engines.
SmartCraft® | The Power to Do More
Mercury SmartCraft® digital technologies refine the entire boating experience to ensure every day on the water reaches its full potential. From intelligent gauges and displays to advanced systems that make boat control easy, SmartCraft gives you the power to do more with your time on the water.
Gauges
SmartCraft digital gauges are a convenient solution for staying in the know. They offer at-a-glance access to precise engine data and select SmartCraft controls on a compact digital interface.
Controls
Enjoy instantly responsive control and precise handling with Mercury digital control systems. Whether driving or docking, every task is made easier so you can take the helm with confidence.
Displays
With SmartCraft, you can integrate your engine with a compatible onboard display, gaining instant access to performance data and SmartCraft controls on the screen you use most.
Connectivity
The Mercury Marine app is the ultimate boating companion. It transforms your mobile device into a hub for monitoring data, connecting with a dealer and viewing helpful content.
Characteristics
| MODEL | Pro XS 175hp | Pro XS 200hp | Pro XS 225hp | Pro XS 250hp | Pro XS 300hp |
|---|---|---|---|---|---|
| Horsepower (HP / kW) | 175 / 129 | 200 / 147 | 225 / 165 | 250 / 184 | 300 / 221 |
| Alternator (Amp / Watt) | 85 amp (1071 Watt) με Idle Charge | 85 amp (1071 Watt) με Idle Charge | 85 amp (1071 Watt) με Idle Charge | 85 amp (1071 Watt) με Idle Charge | 85 amp (1071 Watt) με Idle Charge |
| Colors | Black | Black | Black | Black | Black |
| Smartcraft compatible | Yes | Yes | Yes | Yes | Yes |
| Displacement (L) | 3.4L | 4.6L | 4.6L | 4.6L | 4.6L |
| Dry weight *Lightest model available | 475 lbs / 216 kg | 511 lbs / 232 kg | 511 lbs / 232 kg | 511 lbs / 232 kg | 511 lbs / 232 kg |
| Engine Type | V6 | V8 | V8 | V8 | V8 |
| Recommended fuel | Unleaded Regular 87 Octane Minimum (R+M/2) or 90 R- ON 10% Ethanol Maximum | Unleaded Regular 87 Octane Minimum (R+M/2) or 90 R- ON 10% Ethanol Maximum | Unleaded Regular 87 Octane Minimum (R+M/2) or 90 R- ON 10% Ethanol Maximum | Unleaded Regular 87 Octane Minimum (R+M/2) or 90 R- ON 10% Ethanol Maximum | Unleaded Regular 87 Octane Minimum (R+M/2) or 90 R- ON 10% Ethanol Maximum |
